截齒激光熔覆機BFGK-R002

截齒熔覆專用設備根據鎬型截齒熔覆路徑和工藝要求設計開發，運動機構使用三軸桁架運動機構和雙工位轉臺,實現鎬型截齒面連續高效激光熔覆，適用于批量化、半自動化、精益化截齒生產制造。

The special equipment for cutting pick cladding is designed and developed according to the cladding path and process requirements of pick cutting. The motion mechanism uses a three-axis truss motion mechanism and a double-station rotary table to realize continuous and efficient laser cladding of pick cutting surface. It is suitable for batch, semi?automatic and lean production of cutting pick

產品特點：

1.低熱量輸入，熱影響區小，變形小；

2.合金粉末材料利用率高，損失小

3.柔性化、半自動化，加工周期短，成本低；

4.與基體冶金結合，具有高的結合強度

5.使用特殊合金粉末，熔覆層可具有耐磨、耐腐蝕、耐疲勞等特性

6.熔覆層組織具有完整細粒度結構，具有優異的強度和韌性

Product features：

1. Low heat input, small heat affected zone and deformation;

2. High utilization rate and small loss of alloy powder material

3. Flexible, semi-automatic, short processing cycle and low cost;

4. Metallurgically bonded with the matrix, with high bonding strength

5. Special alloy powder is used, and the cladding layer can be wear-resistant, corrosion resistant and fatigue resistant

6. The cladding structure has a complete fine-grained structure with excellent strength and toughness
